Narrow Inner Ring Cast Iron Housing Material Pillow Block

KHLP208

Narrow Inner Ring Cast Iron Housing Material Pillow Block
Item #101495965
  • 40 mm Shaft Diameter
  • 49.2 mm Center Line To Base Dimension
  • 133 mm Bolt Hole Spacing Range [MIN]
Narrow Inner Ring Cast Iron Housing Material Pillow Block
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options

Alternate Products

NTN Bearing Corp.UCP208D1
NTN Bearing Corp.
UCP/UCPX Series Light-Duty Ball Bearing Pillow Block
Item #101111316
each
Pillow Block Bearing Unit
SKF
Pillow Block Bearing Unit
Item #101174036
each
Wide Inner Ring Cast Iron Housing Material Pillow Block
AMI Bearings Inc.
Wide Inner Ring Cast Iron Housing Material Pillow Block
Item #101509525
each
Ina USA Corp.RSHEY40-XL-N-I
Ina USA Corp.
RSHEY Series Ball Bearing Pillow Block
Item #102192041
each
Wide Inner Ring Cast Iron Housing Material Pillow Block
AMI Bearings Inc.
Wide Inner Ring Cast Iron Housing Material Pillow Block
Item #102066642
each
UCP Series Cast Iron Pillow Block
PT International
UCP Series Cast Iron Pillow Block
Item #102970762
each
UCP Series Cast Iron Pillow Block
PT International
UCP Series Cast Iron Pillow Block
Item #102943429
each
PT InternationalSW208-40UMM
PT International
SW Series Cast Iron Pillow Block
Item #102951352
each
Wide Inner Ring Cast Iron Housing Material Pillow Block
AMI Bearings Inc.
Wide Inner Ring Cast Iron Housing Material Pillow Block
Item #102213982
each
  • 40 mm Shaft Diameter
  • 49.2 mm Center Line To Base Dimension
  • 133 mm Bolt Hole Spacing Range [MIN]
Housing No. LP208
Bearing Type Ball Bearing
Base Height 21 mm
Housing Height 100 mm
Base Width 51 mm
Insert Material AISI 52100 Steel
Bearing Design Non-Expansion
Pillow Block Type Thru-Bolt
Lubrication Fitting Tap 1/8-27 NPT
Bearing Insert KH208
Bolt Holes 2
Bolt Hole Spacing Range [Max] 152 mm
Base Length 184 mm
Housing LP208T
Shaft Dia. 40 mm
Lubrication Relubricatable
Bolt Hole Width 15 mm
Bolt Size M12
Duty Series Normal
Housing Material Cast Iron
Bolt Hole Length 22 mm
Locking Style Eccentric Collar
Mounted Unit Duty Normal-Duty
Length Through Bore 43.7 mm
End Type Open End
Relubricatable Yes
Seal Type Contact Seals
Bolt Hole Spacing 143 mm
Locking Device Setscrew Locking Collar
Bolt Hole Spacing Range [Min] 133 mm
Inch/Metric Metric
Series KHLP200
Housing Construction 1 Piece
Weight 4.82 LB
EAN or UPC 808250121205
