- 7/8" Roller Diameter
- 3/8" Stud Diameter
- 3/8-24 Thread
- Slotted End
- Needle Bearing Design
| Overall Length | 1.40625 in |
| Stud Length | 7/8 in |
| Mounting Overhang | 0.56 in |
| Stud Type | Standard |
| Roller Type | Crowned |
| End Type | Slotted |
| Clamping Dia. | 0.5 in |
| Dynamic Load Rating | 2250 lbf |
| Roller Dia. | 7/8 in |
| Enclosure | Sealed |
| Inch/Metric | Inch |
| Threads per Inch | 24 |
| Clamp Torque | 55 lbf |
| Stud Dia. | 3/8 in |
| Roller Width | 1/2 in |
| Thread Type | UNF |
| Thread Size | 3/8 |
| Material | Steel |
| Thread Pitch | N/A |
| Limiting Speed | 3900 rpm |
| Bearing Type | Needle Bearing |
| Fillet Radius | 0.015 in |
| Working Load | 1320 lbf |
| Weight | 0.012 LB |
| EAN or UPC | 605790185472 |
