- 0.625" Shaft, Contact Seals, Setscrew Locking, Regreasable
description
- The Fafnir SCJ flange cartridges are furnished assembled and ready for mounting by means of four bolts through the flange. SCJ Series are ideal for applications where minimum shaft length is required.The units are assembled with GYA-RRB bearings with positive contact land riding seals and setscrew locking.These units are factory prelubricated, but a grease fitting is provided for relubrication if required.
applications
- Agriculture
- Fans and blowers
- Food processing
- Conveyors
| End Type | Open End |
| Seal Type | Contact Seals |
| Bolt Circle Dia. | 3 in |
| Flange Thickness | 7/16 in |
| Flange Type | 4-Bolt Flange |
| Bearing Type | Ball Bearing |
| Housing No. | T-40124 |
| Housing Material | Cast Iron |
| Housing Width | 0.7031 in |
| Housing Height | 3 in |
| Mounted Unit Duty | Normal-Duty |
| Inch/Metric | Inch |
| Overall Width | 1 in |
| Shaft Dia. | 0.625 in |
| Housing Length | 3 in |
| Length Through Bore | 0.9375 in |
| Bearing Insert | GYA010RRB |
| Style | 4-Bolt Flange |
| Duty | Normal-Duty |
| Lubrication | Relubricatable |
| Bearing Design | Non-Expansion |
| Bolt Hole Spacing | 2 1/8 in |
| Housing Construction | 1 Piece |
| Locking Device | Setscrew Locking Collar |
| Bolt Hole Size | 0.5156 in |
| Weight | 0.83 LB |
| EAN or UPC | 87796056442 |
